𝗕𝗥𝗔𝗡𝗗 𝗡𝗘𝗪 𝗔𝗡𝗗 𝗢𝗥𝗜𝗚𝗜𝗡𝗔𝗟!
𝗦𝗣𝗘𝗖𝗜𝗙𝗜𝗖𝗔𝗧𝗜𝗢𝗡𝗦
Display
• Panel Size: 55"
• Type/Tech: TFT LCD (ADS type, DLED backlight)
• Display Area (mm): 1209.6 (H) x 680.4 (V)
• Aspect Ratio: 9:16
• Native Resolution: 2160x3840
• Colors: 1.07G ( 8 bit +FRC)
• Brightness: 700 nits (typ.)
• Contrast Ratio: 1200:1 (typ.)
• Response Time: 8ms
• Viewing Angles: H=178, V=178 (typ.)
• Backlight Life: 30,000 hours (typ.)
• Surface Treatment: Anti-Glare 3H, Haze 25%
• Orientation: Portrait
Touch
• Type/ Tech: IR Recognition
• Touch Resolution: 32768 x 32768
• Touch Point: 10 points
Input
• HDMI: (2.0) x 2
• RGB / VGA: x1
• DisplayPort: (1.2)x1
• Audio: x1 (3.5mm)
• MIC(Microphone): x1 (3.5mm)
• RS232: x1
Output
• HDMI: x1
• Audio: x1 ( Earphone out)
• SPDIF: x1
• LAN: RJ45: x2
• USB: Type A: x4 (2.0x2 ; 3.0x2)
• Others: Type-C x1 ( USB2.0, DP1.2 , PD15W)
• Speakers: 20Wx2
Compatibility
• RGB PC/HDMI PC: 1920 x 1080 @60Hz
• HDMI: 2160 x 3840 @60Hz
• DisplayPort: 2160 x 3840 @60Hz
• Android Version: 14.0
Multimedia
• Photo: JPG, BMP, PNG
• Video: MP4, MOV, MKV, DAT, MPG, MPEG, AVI, TS, WMV,RM,RMVB, FLV.
• Audio: MP3,WAV, AAC, AVI. MKV.
Preloaded Software
• RevelDigital Player (Activation requires a separate subscription license, sold separately for Revel Digital)
• Manager
Power
• Voltage: 100~240VAC +/- 10% wide range
• Consumption: 61.7W (Typ.), 230W (Max.) Standby mode < 0.5W , Off mode <0.3W
Operating Conditions
• Temperature (º C): 0°C to 40°C
• Humidity: 20% ~ 80% non-condensing
• Regulations: cTUVus, FCC, Energy Star 8.0, CE, CB, RoHs, Erp, EEI, WEEE.
𝗣𝗔𝗖𝗞𝗔𝗚𝗘 𝗖𝗢𝗡𝗧𝗘𝗡𝗧𝗦
• Power cord
• Remote control
• Bottom metal cover and screws
• Key
• Quick start guide
• Compliance statement
𝗗𝗜𝗠𝗘𝗡𝗦𝗜𝗢𝗡𝗦
Dimensions (W x H x D)
• Physical (inch / mm): 30.64 x 73.82 x 17.72 inches/ 778.5 x 1875 x 450 mm
• Packaging (inch / mm): 38.19 x 80.08 x 23.98 inches/ 970x 2034 x 609 mm
Weight
• Net (lb / kg): 138.89 lbs / 63 kg
• Gross (lb / kg): 159.84 lbs / 72.5 kg
𝗪𝗔𝗥𝗥𝗔𝗡𝗧𝗬
• 3-years Manufacturers Warranty
• All shipping fees shall be shouldered by the buyer.
• Kindly send us a message on how to claim the warranty
