TP-Link TL-WR840N 300Mbps Wireless N Router

𝗕𝗥𝗔𝗡𝗗 𝗡𝗘𝗪 𝗔𝗡𝗗 𝗢𝗥𝗜𝗚𝗜𝗡𝗔𝗟!

𝗦𝗣𝗘𝗖𝗜𝗙𝗜𝗖𝗔𝗧𝗜𝗢𝗡𝗦
HARDWARE FEATURES
• Interface
• 4 10/100Mbps LAN PORTS
• 1 10/100Mbps WAN PORT
• Button: WPS/RESET Button
• Antenna: 2 Antennas
• External Power Supply: 9VDC / 0.6A
• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Dimensions ( W x D x H ): 7.2 x 5.0 x 1.4in.(182 x 128 x 35 mm)

WIRELESS FEATURES
• Frequency: 2.4-2.4835GHz
• Signal Rate
• 11n: Up to 300Mbps(dynamic)
• 11g: Up to 54Mbps(dynamic)
• 11b: Up to 11Mbps(dynamic)
• Reception Sensitivity
• 270M: -68dBm@10% PER
• 130M: -68dBm@10% PER
• 108M: -68dBm@10% PER
• 54M: -68dBm@10% PER
• 11M: -85dBm@8% PER
• 6M: -88dBm@10% PER
• 1M: -90dBm@8% PER
• Transmit Power
• CE: <20dBm
• FCC: <30dBm
• Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
• Wireless Security: 64/128-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK

OTHERS
• Certification: CE, RoHS
• System Requirements: Windows 2000/XP/Vista™, Windows 7, Windows 8, Windows 8.1, Windows 10 or Mac OS or Linux-based operating system
• Environment
• Operating Temperature: 0℃~40℃ (32℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing

𝗣𝗔𝗖𝗞𝗔𝗚𝗘 𝗖𝗢𝗡𝗧𝗘𝗡𝗧𝗦
• 1 x Wireless N Router TL-WR840N
• 1 x Power supply unit
• 1 x Resource CD
• 1 x Ethernet Cable
• 1 x Quick Installation Guide
