𝗕𝗥𝗔𝗡𝗗 𝗡𝗘𝗪 𝗔𝗡𝗗 𝗢𝗥𝗜𝗚𝗜𝗡𝗔𝗟!
𝗧𝗘𝗖𝗛𝗡𝗜𝗖𝗔𝗟 𝗦𝗣𝗘𝗖𝗜𝗙𝗜𝗖𝗔𝗧𝗜𝗢𝗡𝗦
WIRELESS
Standards
• Wi-Fi 5
• IEEE 802.11ac/n/a 5 GHz
• IEEE 802.11n/b/g 2.4 GHz
Wi-Fi Speeds
• AC1200
• 5 GHz: 867 Mbps (802.11ac)
• 2.4 GHz: 300 Mbps (802.11n)
Wi-Fi Range
• 3-4 Bedroom Houses (3-pack)
• TP-Link Mesh Technology
• Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
• 2× Antennas (Internal)
• Multiple antennas form a signal-boosting array to cover more directions and large areas
• Beamforming
• Concentrates wireless signal strength towards clients to expand Wi-Fi range
Wi-Fi Capacity
• Medium
• Dual-Band
• Distribute devices to different bands for optimal performance
• MU-MIMO
• Simultaneously communicates with multiple MU-MIMO clients
Working Modes
• Router Mode
• Access Point Mode
HARDWARE
• Processor: Qualcomm CPU
Ethernet Ports
• 2× 10/100 Mbps Ports
• *Per Deco Unit
• Supports WAN/LAN auto-sensing
Buttons
• Button: Reset
SECURITY
Wi-Fi Encryption
• WPA-Personal
• WPA2-Personal
Network Security
• SPI Firewall
• Access Control
Guest Network
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
SOFTWARE
Protocols
• IPv4
• IPv6
Parental Controls
• URL Filtering
• Time Controls
WAN Types
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP
• Quality of Service: QoS by Device
Cloud Service
• OTA Firmware Upgrade
• TP-Link ID
• DDNS
NAT Forwarding
• Port Forwarding
• UPnP
IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN
• DHCP
• Address Reservation
• DHCP Client List
• Server
• DDNS: TP-Link
• Management: Deco App
PHYSICAL
Dimensions
• (W×D×H) 3.6 × 3.6 × 7.5 in
• (90.7 × 90.7 × 190 mm)
OTHERS
• System Requirements: Android 4.4 or later
iOS 9.0 or later
• Certifications: CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
• Environment: Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
TEST DATA
Wi-Fi Transmission Power
• CE:
• <20 dBm (2.4 GHz)
• <23 dBm (5 GHz)
FCC:
• <30 dBm
